# Fitting interactive web graphics into a data science workflow
### Carson Sievert
### Slides: <a href="https://talks.cpsievert.me" class="uri">https://talks.cpsievert.me</a> <br /> <br /> <i class="fa  fa-twitter "></i> <a href='https://twitter.com/cpsievert'><span class="citation" data-cites="cpsievert">@cpsievert</span></a> <br /> <i class="fa  fa-github "></i> <a href='https://github.com/cpsievert'><span class="citation" data-cites="cpsievert">@cpsievert</span></a> <br /> <i class="fa  fa-envelope "></i> <a href="mailto:cpsievert1@gmail.com">cpsievert1@gmail.com</a> <br /> <i class="fa  fa-globe "></i> <a href="https://cpsievert.me/" class="uri">https://cpsievert.me/</a> <br /> <br /> Slides released under <a href='https://github.com/cpsievert/talks/blob/gh-pages/LICENSE'>Creative Commons</a>

---

class: principles

## About me

* PhD in statistics at Iowa State with Dr. Heike Hofmann (Dec 2016)

  * Thesis: [Interfacing R with Web Technologies for Interactive Statistical Graphics and Computing with Data](http://lib.dr.iastate.edu/etd/15422/)

* CEO of [Sievert Consulting](https://consulting.cpsievert.me/) LLC (Jan 2017)

* Clients include: plotly, NOAA, O'Reilly, Sandia

  * Looking for more part-time projects

* The majority of my work is in interactive data visualization

  * Primarily work in R, dabble in JavaScript and python.

  * Maintain numerous R packages including: plotly, LDAvis, pitchRx

---
background-image: url(../20171207/workflow.svg)
background-size: contain
class: inverse

# Data Science Workflow

---
background-image: url(../20171207/workflow1.svg)
background-size: contain
class: inverse

# Expository vis

### The web is the preferred medium for communicating results

### Assuming you know _exactly_ what you want to visualize, many good data vis frameworks exist (e.g. [d3.js](https://d3js.org/))

---
background-image: url(../20171207/workflow2.svg)
background-size: contain
class: inverse

# Exploratory vis

### Web technologies weren't designed for data exploration
### People [seem to have forgotten](http://flowingdata.com/2016/03/08/what-i-use-to-visualize-data/) how interative graphics can augment exploration

---
class: principles

## Interactive graphics augment exploration!

* Identify structure that otherwise goes missing ([Tukey 1972](http://stat-graphics.org/movies/prim9.html)).

* "Search for information quickly without fully specified questions" ([Unwin & Hofmann, 2000](https://www.researchgate.net/publication/2425912_GUI_and_Command-line_-_Conflict_or_Synergy))
    * "[Multiple linked views] are the optimal framework for posing queries about data" ([Buja et al 1996](https://www.jstor.org/stable/1390754))

    * What about inference? See visual ([Majumder et al 2013](http://amstat.tandfonline.com/doi/abs/10.1080/01621459.2013.808157?journalCode=uasa20#.Wl01_ZM-dTY)) and post-selection ([Berk et al 2013](https://projecteuclid.org/euclid.aos/1369836961)) inference.

* Better understand/diagnose models ([Wickham, Cook, & Hofmann 2015](http://onlinelibrary.wiley.com/doi/10.1002/sam.11271/abstract)).

.footnote[
---

Statisticians were building (very advanced!) int graphics systems decades ago --   <http://stat-graphics.org/movies/>
]

---
class: principles

## Interactive graphics augment exploration!

* Identify structure that otherwise goes missing ([Tukey 1972](http://stat-graphics.org/movies/prim9.html)).

* "Search for information quickly without fully specified questions" ([Unwin & Hofmann, 2000](https://www.researchgate.net/publication/2425912_GUI_and_Command-line_-_Conflict_or_Synergy))
    * "[Multiple linked views] are the optimal framework for posing queries about data" ([Buja et al 1996](https://www.jstor.org/stable/1390754))

    * What about inference? See visual ([Majumder et al 2013](http://amstat.tandfonline.com/doi/abs/10.1080/01621459.2013.808157?journalCode=uasa20#.Wl01_ZM-dTY)) and post-selection ([Berk et al 2013](https://projecteuclid.org/euclid.aos/1369836961)) inference.

* <div class="highlight">Better understand/diagnose models</div> ([Wickham, Cook, & Hofmann 2015](http://onlinelibrary.wiley.com/doi/10.1002/sam.11271/abstract)).

---
## Deeper look at linear model diagnostics

```r
# choose a model by AIC stepping backwards
mod <- step(lm(mpg ~ ., data = mtcars), trace = FALSE)
formula(mod)
```

```r
mpg ~ wt + qsec + am
```

```r
# produce (static ggplot2) diagnostic plot
library(GGally)
pm <- ggnostic(mod, mapping = aes(color = am))

# make it interactive
library(plotly)
ggplotly(pm)
```

---

???

The noticeably high value of cooksd suggests a large influence on the fitted model. Highlighting this point makes it obvious that it is influential since it has a unusually high response/residual in a fairly sparse region of the design space (i.e., it has a pretty high value of wt) and removing it would significantly reduce the estimated standard deviation (sigma). By comparison, the other two observations with similar values of wt have a response value very close to the overall mean, so even though their value of hat is high, their value of sigma is low.

---
### See relationships evolve over time ([made via ggplot2](https://plotly-book.cpsievert.me/linking-animated-views.html))

---
background-image: url(../20170803/tour.gif)
background-size: contain
class: middle

### Interactively [plot models in data space](tour.html) ([code](https://github.com/ropensci/plotly/blob/master/demo/animation-tour-USArrests.R))

---
class: middle, inverse

# Designing, building, maintaining, and publishing a *general purpose* vis library (e.g. plotly) is very hard!

### Grad students: make your life easier...design a *domain specific* tool

---
background-image: url(LDAvis.svg)
background-size: contain

## LDAvis: interactive vis tools for interpreting topic models

.footnote[
### <https://github.com/cpsievert/LDAvis>
]

---
class: principles

## Interactive graphics augment exploration!

* Identify structure that otherwise goes missing ([Tukey 1972](http://stat-graphics.org/movies/prim9.html)).

* Search for information quickly without fully specified questions ([Unwin & Hofmann, 2000](https://www.researchgate.net/publication/2425912_GUI_and_Command-line_-_Conflict_or_Synergy))
    * <div class="highlight">[Multiple linked views] are the optimal framework for posing queries about data</div> ([Buja et al 1996](https://www.jstor.org/stable/1390754))

    * What about inference? See visual ([Majumder et al 2013](http://amstat.tandfonline.com/doi/abs/10.1080/01621459.2013.808157?journalCode=uasa20#.Wl01_ZM-dTY)) and post-selection ([Berk et al 2013](https://projecteuclid.org/euclid.aos/1369836961)) inference.

* Better understand/diagnose models ([Wickham, Cook, & Hofmann 2015](http://onlinelibrary.wiley.com/doi/10.1002/sam.11271/abstract)).

---
background-image: url(../20171207/epl.png)
background-size: contain
class: inverse

---
background-image: url(../20171207/epl.png)
background-size: contain
class: middle

.pull-left[
# Neat, but I can't:

<div class="principles">
• Query different years <br />
• Zoom/pan
</div>
]

---
background-image: url(../20171207/epl.gif)
background-size: contain
class: principles

---
background-image: url(../20171207/epl.gif)
background-size: contain

# Nice for comparing across seasons within teams

.footnote[
### What about comparing across teams with seasons?
]

---
background-image: url(https://i.imgur.com/Id2nVFG.gif)
background-size: contain

---
background-image: url(https://i.imgur.com/Id2nVFG.gif)
background-size: contain

# Generally useful for comparing within/across panels!

---
## An example with Texas housing prices

```r
library(dplyr)
tx <- txhousing %>%
  select(city, year, month, median) %>%
  filter(city %in% c("Galveston", "Midland", "Odessa", "South Padre Island"))
tx
```

```r
#> # A tibble: 748 x 4
#>         city  year month median
#>        <chr> <int> <int>  <dbl>
#>  1 Galveston  2000     1  95000
#>  2 Galveston  2000     2 100000
#>  3 Galveston  2000     3  98300
#>  4 Galveston  2000     4 111100
#>  5 Galveston  2000     5  89200
#>  6 Galveston  2000     6 108600
#>  7 Galveston  2000     7  99000
#>  8 Galveston  2000     8  96200
#>  9 Galveston  2000     9 104000
#> 10 Galveston  2000    10 118800
#> # ... with 738 more rows
```

---
### Compare within and across cities

```r
*TX <- crosstalk::SharedData$new(tx, ~year)
p <- ggplot(TX, aes(month, median, group = year)) + geom_line() +
  facet_wrap(~city, ncol = 2)
highlight(ggplotly(p), dynamic = T, persistent = T, selectize = T)
```

---
class: inverse, middle, center

# Note: 'crosstalk highlighting' works _without shiny_ (more later). Here are some examples _with shiny_

---
background-image: url(https://i.imgur.com/T7GSpv9.gif)
background-size: contain
class: principles

<https://github.com/cpsievert/zikar>

---
background-image: url(https://i.imgur.com/MGbR5AI.gif)
background-size: contain
class: principles

<div align="right">
<a href='https://github.com/cpsievert/bcviz'>https://github.com/cpsievert/bcviz</a>
</div>

---
background-image: url(https://i.imgur.com/csIUJX0.gif)
background-size: contain
class: principles

<https://github.com/cpsievert/apps>

---

.pull-left[
<img src="../gifs/drowning.gif" width="80%"/>
]

.pull-right[
# Lost in a sea of interactive techniques?

### Focus on the analysis task/question first

### Often many different ways to do the same thing!
]

---
background-image: url(../20171207/taxonomy.svg)
background-size: contain
class: bottom, inverse

### _Interactive High-Dimensional Data Visualization_, [Buja et al 1996](https://www.jstor.org/stable/1390754); authors of [GGobi](http://ggobi.org)

---
class: center, middle

# Should an interactive graphics system be purely graphical (from a user perspective)?

.footnote[
### Over a system where users have to write code?
]

---
class: inverse, center, middle

### From Hofmann & Unwin, [*GUI and Command-line - Conflict or Synergy?*](https://www.researchgate.net/publication/2425912_GUI_and_Command-line_-_Conflict_or_Synergy)

# "Statistical software should be expressive, powerful, fast and reliable, but it should also be intuitive, easy to use, flexible, forgiving and consistent"

---
class: inverse, center, middle

# Statistical software should be <font color='red'>expressive, powerful, fast and reliable</font>, but it should also be <font color='#119dff'>intuitive, easy to use, flexible, forgiving and consistent</font>

.footnote[

### <font color='red'>Programming languages are good at this!</font>

### <font color='#119dff'>Graphical interfaces are good at this!</font>

]

---
background-image: url(https://i.imgur.com/c7NJRa2.gif)
background-size: contain
class: inverse

# The ideal 'power' system has best of both worlds

---
background-image: url(../gifs/swamp.gif)
background-size: contain
class: inverse, center, bottom

## It is all too easy for statistical thinking to be **swamped by programming tasks.** -- Brian D. Ripley

---
## What's in the swamp?

.pull-left[
## Exploratory mud

<div class="principles">
• Start-up <br/>
• Iteration <br/>
• Dead-end
</div>
]

.pull-right[
## Expository mud

<div class="principles">
• Deployment <br/>
• Latency
</div>
]

---
class: inverse

## *How* to drain the swamp? ☝ 🍊

.pull-left[
## Exploratory mud

<div class="principles">
• Start-up <br/>
• Iteration <br/>
• Dead-end
</div>
]

.pull-right[
## Expository mud

<div class="principles">
• Deployment <br/>
• Latency
</div>
]

.footnote[
### What follows are some details & my suggestions about how one might go about it
]

---

## How to drain the swamp? <div class="highlight"> R 📦s that avoid </div>

.pull-left[
## Exploratory

<div class="principles">
<div class="highlight"> • Start-up mud</div> <br/>
• Iteration <br/>
• Dead-end
</div>
]

.pull-right[
## Expository

<div class="principles">
• Deployment <br/>
• Latency
</div>
]

<br/>

<div class="highlight">
* Getting started should be easy!
  * Easy install (CRAN) and good documentation (e.g., [pkgdown](http://pkgdown.r-lib.org/) site)
  * Build upon existing work!
<div>

---
background-image: url(../20171207/europe.png)
background-size: contain
class: inverse

---

```r
library(tidyverse)

*# read and clean data
d <- read_csv('GEOSTAT_grid_POP_1K_2011_V2_0_1.csv') %>%
  rbind(read_csv('JRC-GHSL_AIT-grid-POP_1K_2011.csv') %>%
          mutate(TOT_P_CON_DT = '')) %>%
  mutate(
    lat = as.numeric(gsub('.*N([0-9]+)[EW].*', '\\1', GRD_ID))/100,
    lng = as.numeric(gsub('.*[EW]([0-9]+)', '\\1', GRD_ID)) * ifelse(gsub('.*([EW]).*', '\\1', GRD_ID) == 'W', -1, 1) / 100
  ) %>%
  filter(lng > 25, lng < 60) %>%
  group_by(lat = round(lat, 1), lng = round(lng, 1)) %>%
  summarize(value = sum(TOT_P, na.rm = T))  %>%
  ungroup() %>%
  tidyr::complete(lat, lng)

*# visualize
ggplot(d, aes(lng, lat + 5*(value / max(value, na.rm = T)))) +
  geom_line(
    aes(group = lat, text = paste("Population:", value)),
    size = 0.4, alpha = 0.8, color = '#5A3E37', na.rm = T
  )
```

---

```r
library(tidyverse)
*library(crosstalk)
*library(plotly)

d <- read_csv('GEOSTAT_grid_POP_1K_2011_V2_0_1.csv') %>%
  rbind(read_csv('JRC-GHSL_AIT-grid-POP_1K_2011.csv') %>%
          mutate(TOT_P_CON_DT = '')) %>%
  mutate(
    lat = as.numeric(gsub('.*N([0-9]+)[EW].*', '\\1', GRD_ID))/100,
    lng = as.numeric(gsub('.*[EW]([0-9]+)', '\\1', GRD_ID)) * ifelse(gsub('.*([EW]).*', '\\1', GRD_ID) == 'W', -1, 1) / 100
  ) %>%
  filter(lng > 25, lng < 60) %>%
  group_by(lat = round(lat, 1), lng = round(lng, 1)) %>%
  summarize(value = sum(TOT_P, na.rm = T))  %>%
  ungroup() %>%
  tidyr::complete(lat, lng)

*# define latitude as "interaction unit"
*sd <- SharedData$new(d, ~lat)

ggplot(sd, aes(lng, lat + 5*(value / max(value, na.rm = T)))) +
  geom_line(
    aes(group = lat, text = paste("Population:", value)),
    size = 0.4, alpha = 0.8, color = '#5A3E37', na.rm = T
  )

*ggplotly()
```

---

---
## How to drain the swamp? <div class="highlight"> R 📦s that avoid </div>

.pull-left[
## Exploratory

<div class="principles">
• Start-up <br/>
• <div class="highlight">Iteration mud</div> <br/>
• Dead-end
</div>
]

.pull-right[
## Expository

<div class="principles">
• Deployment <br/>
• Latency
</div>
]

<br/>

<div class="highlight">
* Reduce distance between data and visuals
  * Leverage [grammar of graphics](https://www.amazon.com/Grammar-Graphics-Statistics-Computing/dp/0387245448) (e.g. **ggplot2**, **vega**, etc)
  * Leverage tidy data principles (e.g., **dplyr**, **tidyr**, **broom**, etc)
<div>

---
## Some motivation: query missing values by city

---
class: bottom, left
background-image: url(../20171207/pipeline.svg)
background-size: contain

## The 'data pipeline'

---

## The implementation

```r
library(plotly)
library(crosstalk)

# define city as 'unit of interaction'
sd <- SharedData$new(txhousing, ~city)

# initiate plot object, ensuring one mark per group
base <- plot_ly(sd, color = I("black")) %>%
  group_by(city)

# transform plot object as if it's a data frame
p1 <- base %>%
  summarise(miss = sum(is.na(median))) %>%
  filter(miss > 0) %>%
  arrange(miss) %>%
  add_bars(x = ~miss, y = ~factor(city, levels = city)) %>%
  layout(barmode = "overlay")

p2 <- add_lines(base, x = ~date, y = ~median, alpha = 0.3)

subplot(p1, p2, titleX = TRUE, widths = c(0.3, 0.7)) %>%
  highlight(dynamic = TRUE, persistent = TRUE, selectize = TRUE)
```

---
## How to drain the swamp? <div class="highlight"> R 📦s that avoid </div>

.pull-left[
## Exploratory

<div class="principles">
• Start-up <br/>
• Iteration<br/>
• Dead-end
</div>
]

.pull-right[
## Expository

<div class="principles">
<div class="highlight"> • Deployment mud </div> <br/>
• Latency
</div>
]

<br/>

<div class="highlight">
Produce a standalone web page whenever possible
<div>

---
background-image: url(../20171207/server-client.svg)
background-size: contain

---
background-image: url(../20171207/server-client.svg)
background-size: contain
class: middle, center

# Standalone web pages are **much** easier to share, deploy, scale, and maintain.

---
class: middle, bottom
background-image: url(../20171207/pipeline.svg)
background-size: contain

# Where is the pipeline?

---
background-image: url(../20171207/crosstalk.svg)
background-size: contain

## The general model

.footnote[
### Links are specified in R, but the "updating logic" is JavaScript -- no server required!
]

---
## How to drain the swamp? <div class="highlight"> R 📦s that avoid </div>

.pull-left[
## Exploratory

<div class="principles">
• Start-up <br/>
• Iteration <br/>
• Dead-end
</div>
]

.pull-right[
## Expository

<div class="principles">
• Deployment <br/>
<div class="highlight">• Latency mud</div>
</div>
]

<br/>

<div class="highlight">
* User activity drops w/ delay of 500ms (<a href="https://idl.cs.washington.edu/papers/latency/">Liu & Heer 2014</a>)
  * Support canvas-based (e.g. WebGL) as well as vector (e.g. SVG)
  * Provide API for modifying plots in R (& JavaScript!)
<div>

---

## Base map layer does not require a redraw with a new fillcolor!

---

### Leverage any [plotly.js function](https://plot.ly/javascript/plotlyjs-function-reference/) to *modify* a plot via `plotlyProxy()`

```r
library(shiny)
library(plotly)

ui <- fluidPage(
  selectInput("color", "Canada's fillcolor", colors()),
  plotlyOutput("map")
)

server <- function(input, output, session) {

  output$map <- renderPlotly({
    map_data("world", "canada") %>%
      group_by(group) %>%
      plot_mapbox(x = ~long, y = ~lat, color = I("black")) %>%
      add_polygons()
  })

  observeEvent(input$color, {
    plotlyProxy("map", session) %>%
      plotlyProxyInvoke("restyle", list(fillcolor = toRGB(input$color)))
  })
}

shinyApp(ui, server)
```

---
## How to drain the swamp? <div class="highlight"> R 📦s that avoid </div>

.pull-left[
## Exploratory

<div class="principles">
• Start-up <br/>
• Iteration <br/>
<div class="highlight">• Dead-end mud</div>
</div>
]

.pull-right[
## Expository

<div class="principles">
• Deployment <br/>
• Latency
</div>
]

<br/>

<div class="highlight">
* Integrate with other libraries that complement yours
<div>

---
background-image: url(../20170803/plotlyLeaflet.gif)
background-size: contain

## plotly & leaflet

---
background-image: url(../20171207/workflow2.svg)
background-size: 250px
background-position: 90% 8%
class: inverse, center, middle

### No matter how complex and polished the individual operations are, it is often

# the quality of the glue that most directly determines the power of the system.

.footnote[
Quote from Hal Abelson -- part of the [tidyverse manifesto](https://cran.r-project.org/package=tidyverse)
]

---

```r
library(plotly)
library(leaflet)
library(crosstalk)

*# good glue requires uniform data structures
*sd <- SharedData$new(quakes)

p <- plot_ly(sd, x = ~depth, y = ~mag) %>%
  add_markers(alpha = 0.5) %>%
  highlight("plotly_selected", dynamic = TRUE)

map <- leaflet(sd) %>%
  addTiles() %>%
  addCircles()

bscols(widths = c(6, 6), p, map)
```

---
## How to drain the swamp? <div class="highlight"> R 📦s that avoid </div>

.pull-left[
## Exploratory

<div class="principles">
• Start-up <br/>
• Iteration <br/>
<div class="highlight">• Dead-end mud</div>
</div>
]

.pull-right[
## Expository

<div class="principles">
• Deployment <br/>
• Latency
</div>
]

<br/>

<div class="highlight">
* Every 📦 that reduces start-up/iteration will *always* have dead ends.
* What you leave out is just as important as what you put in!
  * Ask yourself: can others do powerful things _quickly_?
* Strive for 80/20 rule: 80% easy, other 20% possible
<div>

---

#### Provide tools for "power users"

```
plot_ly(mtcars, x = ~wt, y = ~mpg) %>%
  add_markers(text = ~paste0("http://google.com/#q=", rownames(mtcars))) %>%
  htmlwidgets::onRender("function(el, x) {
    el.on('plotly_click', function(d) {
      var pt = d.points[0];
      var url = pt.data.text[pt.pointNumber];
      window.open(url);
    });
  }")
```

---
## How to drain the swamp? <div class="highlight"> R 📦s that avoid </div>

.pull-left[
## Exploratory

<div class="principles">
• Start-up <br/>
• Iteration <br/>
<div class="highlight">• Dead-end mud</div>
</div>
]

.pull-right[
## Expository

<div class="principles">
• Deployment <br/>
• Latency
</div>
]

<br/>

<div class="highlight">
* Interactive graphics software must be opinionated
* Not enough statisticians influence design nowadays
  * Tech landscape shifted from C/Java to JavaScript
  * We need more focus on techniques for data analysis tasks!
<div>

---
background-image: url(../20161212a/plotly.svg)
background-size: contain

## The plotly ecosystem

---
background-image: url(../20161212a/plotly.svg)
background-size: contain

## TODO: highlight the interface

---

## Summary

#### Interactive graphics *can* augment exploratory analysis, but are only *practically* useful when we can iterate quickly

.pull-left[
## Exploratory mud

* Start-up
* Iteration
  * Reduce distance between data and visuals
  * Leverage grammar of graphics and tidy-data principles
* Dead-end
  * Integrate with other libraries that complement yours
  * Strive for 80/20 rule: 80% easy, other 20% possible
  * Interactive techniques should empower data analysis tasks
]

.pull-right[
## Expository mud

* Deployment
  * Use standalone web pages whenever possible
* Latency
  * User activity drops w/ delay of 500ms
]

---
class: middle, center, principles

## Thanks! Questions?

Slides: <https://talks.cpsievert.me>

Learn more: <https://plotly-book.cpsievert.me>

#### Contact

<i class="fa  fa-twitter "></i> <a href='https://twitter.com/cpsievert'>@cpsievert</a> <br />
<i class="fa  fa-github "></i> <a href='https://github.com/cpsievert'>@cpsievert</a> <br />
<i class="fa  fa-envelope "></i> <cpsievert1@gmail.com> <br />
<i class="fa  fa-globe "></i> <https://cpsievert.me/>
